HEIMDALL: Smart low-resolution vision sensor for movement detection

    HEIMDALL

    The HEIMDALL IP platform functionalities consist of a low image resolution processing designed to offer rapid interpretation of images.

    HEIMDALL is suitable for multiple applications such as the detection of objects and intelligent motion interpretation. ASIC designs based on HEIMDALL specifications have already been used across a range of industrial and IoT applications for motion and luminance detection, object tracking, and data communication via RF links.

    Resources

    Contact us
    shutterstock_723907804 Optical Monitoring H400

    HEIMDALL Key Features

    • Low image resolution of 64×64 pixels, bundled with a core image signal processing to achieve a high-level classification of image content.

    • Silicon area of just 9mm2 for the RAM and image sensor, ideal for small IoT applications.

    • Ambient light sensor RGB

    • Can be combined with energy-harvesting technology to create a single autonomous ASIC platform design.

    Market Applications

    Building and Infrastructure Automation

    • Occupancy and people

    • Counting

    • Smart Lighting

    • Factory access control and automatic doors

    • Highway & traffic surveillance/vehicle counting

    Production infrastructure

    • Smart Agriculture, including pesticide detection (NIR) levels

    • Food and material quality inspection and sorting automation

    Security, surveillance and safety

    • Factory line Smart Safety (Safety alarms)

    • Complement to Video

    • Surveillance and intrusion detection

    • Eyewear protection

    Test & Measurement

    • Chemical Analytical composition

    • Material inspection

    • High Dynamic Intrusion

    • High dynamic global shutter optics

    Silicon Proven IP platforms for Faster ASIC Development

    Developing a custom ASIC can be complex, this is why Presto Engineering has developed a portfolio of pre-validated reference designs that significantly reduce cost, risk and accelerates your time-to-market.
