Single chip 915 MHz transceiver for toll road tag applications

Development of an 915MHz  toll road identification and payment device for use in North America.

During this project, we studied a fully integrated communication and payment processing chip to be used for 915MHz compliant toll road payment systems in North America.

The chip includes a 915MHz AM receiver as well as a RF-DAC based transmitter with high linearity output power control. The device includes internal matching network to allow for seamless integration with external antenna. Also included is a Brown Out detector and power down control to optimize battery life.

Application areas :

Application areas include toll road systems motorways, bridges, urban areas, ferries etc.

Top technical features:

• Based on 915MHz communication.
• Battery operated in range 3.6 – 1.8 V
• Ultra low power sleep current consumption ( < 5uA )
• High input power dynamic range -23dBm to +10dBm.
• Sensitivity control 0.1 dBc
• Highly linearly RF-DAC based transmitter with output power control in the range -10dBm to 1 dBm.
